AllFocusTM EDF Image Gallery - Nugget #2
Images of a Gold Nugget from the collection of Gold Art Planet were acquired with Motorized Lift controlled by ZStackTool and Canon Digital Rebel camera controlled by Canon Remote Capture. The lens was Canon EF 100mm f/2.8 USM Macro Lens. Illumination was provided by three lamps placed around the specimen at 120 deg. Aperture = 6.3, shutter speed = 1/100. Spacing in the stack was 0.25 mm. Z-stack of 30 images was processed with AllFocus V0.98.
Left image is the Z-stack animation (not all images from the stack are shown in the animation), right image is the Merged Image produced by AllFocus.
